MU Patch Cord Jumper , Upc Cable Optical Fiber G652D 3.0mm

Upc Patch Cord Optical Patch Cord Jumper 9 / 125 MU TO MU UPC G652D LSZH 3.0mm SM

Description:

100% pre-terminated and tested in factory to ensure transfer performance

Rapid configuration and networking, reduce installation time.

Supports 40G and 100G network applications Jacket material: LSZH, OFNR, OFNP available.

Available in OM1, OM2, OM3, OM4, G652D, G657 fiber glass.

Supports up to 4F, 8F, 12F, 24F, 48F, 72F, 96F, 144F, products are availableOEM service is avaibable .

According to the transmission medium, it divides Single Mode and Multi Mode; according to the connector structure type, it divides FC, SC, ST, MU, E2000, LC etc.; according to the polished ceramic end-face, it divides PC, UPC and APC.

Specification:

Connector Type:	MU-MU OR
Polish:	UPC/APC Optional
Length:	1M.2M 3M...or
Fiber type:	0.9/125 μ m
Wavelength:	1310nm-1500nm
Mode:	Single Mode
Color:	yellow..or
Insertion loss: B	≤ 0.3dB
Return loss:	≥ 50dB
Tensile strength:	40N
Times of insertion and removal:	> 1000 Times
Vibration:	< 0.1dB
Minimum bending radius:	3.8cm
Material:	PVC
Storage temperature:	- 40 ℃ to75 ℃
Operating Temperature:	-40°C to 75°C

MU Patch Cord Jumper , Upc Cable Optical Fiber G652D 3.0mm

FAQ:

1: How can you guarentee the quality ?
A: Build on our perfect quality management system, all of our products were 100% tested before the shipment.

2: Do you provide OEM service ?
A: Yes, we can print your logo or label on the products or on the box.

3: What's your payment terms ?
A: We accept T/T, Western Union, Money Gram, Paypal.
For samples: 100% payment. Formal order: 30% as deposit, 70% balance payment before shipment.
