2.0mm Multimode Fiber Patch Cord , LC LC Om3 Patch Cord Aqua

Product Categories

Shenzhen Hong An Jia Technology Co.,Ltd.

Contact Now

Ask Lasest Price
Brand Name :
Model Number :	LC/UPC-LC/UPC Patch Cord
Certification :	CE Rohs SGS ISO
Price :	Price : Negotiable
Payment Terms :	Payment Terms:T/T, L/C,paypal,Western Union
Supply Ability :	Supply Ability :150000pcs/month
Delivery Time :	Delivery Time :3 to 5 days for sample orders, 7 to 15days for bulk order

Add to Cart

LC - LC Multimode Fiber Patch Cord 2.0mm Duplex Multimode 50/125 Om3 Aqua Color

Description :

The fiber optic patch cord is a length of optical cable with

connectors fixed on two ends to realize the optical path active connection. Pigtail is a length fiber

cable with only one connector fixed on one end. If both sides of the connector or its end-face are

different, we call it hybrid patch cord. According to the transmission medium, it divides Single Mode

and Multi Mode; according to the connector structure type, it divides FC, SC, ST, MU, D4, E2000,

LC etc.; according to the polished ceramic end-face, it divides PC, UPC and APC.

Specification:

Pigtail Connector	PC (SM)	UPC (SM)	APC (SM)	MM
Return Loss (dB)	≥45	≥50	≥60	≥35
Insertion Loss (dB)	≤0.2 (max≤0.3)
Repeatability (dB)	≤0.1
Durability(1/Matings)	≥500
Operation Temperature (°C)	-25~+70
Tensile Strength (N)	≥90 (Φ3.0), ≥70 (Φ2.0), Φ0.9
Fiber	9/125um, 50/125um,62.5/125um,ect
diameter	0.9mm 2.0mm, 3.0mm etc
Cable material	PVC, LSZH
Cores	Simplex, duplex, 4cores, 6cores, 8cores, 12cores etc

2.0mm Multimode Fiber Patch Cord , LC LC Om3 Patch Cord Aqua
